FC-4C Animal Feed Chopper

FC-4C motor-driven chaff cutter is simpler and more convenient, a gearbox adjusts the straw length, and another can be adjusted the feed raw materials when the fodder chopper fault, so that users convenience to facilitate the use of the straw kneading machine.

fc 4c chaff cutter banner

WHAT CAN OUR CHAFF CUTTER DO?

FC-4C Motor-Driven Chaff Cutter Machine is mainly used for cutting green or yellow crop straws, corn straws, rice straws, and other forages, also for kneading and grinding various crop straws such as corn straw, soybean straw, cotton straw, pasture, and so on.

These crops’ straws can be cut into forage material. Improve the utilization rate of pasture, silage is fresher than green feed, and the nutrition will not be reduced. It is sweet and sour. After silage, it can remove odor and toxin, stimulate livestock appetite, increase feed intake, and can promote the growth and development of sheep and can be stored for a long time, can reduce parasitic diseases.

It is a good helper for families raising cattle, sheep, horses, deer, and other animals. It is applicable for ranches and specialized feeding households. The FC series chaff cutter machine is a piece of high-quality agricultural product equipment worthy of the trust of large farms and professional farmers.



OUR FC SERIES CHAFF CUTTER FEATURES

  • Steel frame structure, small volume, lightweight, convenient to move
  • High-strength bolts are used for connection to provide safe and reliable operation;
  • Feeding Rollers in our Chaff Cutter are made by Casting Iron with longer service life;
  • Cutting part adopt two, three, four, six groups plane oblique blades
  • More security than the traditional manual hay cutter
  • Our hay cutting machine is guaranteed for 12 months



WORKING PRINCIPLE OF CHAFF CUTTER

Chaff cutter machines’ basic structure: it is made up of a feeding part, cutting and throwing part, transmitting part, walking part, and safety device, so it is reasonably structured and easy to be moved with autonomous feeding. It is safe and reliable.
a. The feeding structure comprises the feeding platform, transmitting chains, feeding roller, fixed cutter blade, and fixed cutter holder.
b. The cutting and throwing structures are mainly made up of a motion knife, knife frames, and locking bolts.
c. The transmission structure consists of a triangle belt, transmitting axle, gears, universal joints, and chains.
d. A walking structure is made up of ground wheels or walking rubber wheels and a traction frame.
e. defensive device contains several safety hoods
Chaff cutter machine working principle: It is powered by a motor (single-cylinder diesel engine, or four-wheel tractor). The power is transmitted to the main shaft, and the gear at the other end of the main shaft transmits the speed-regulated power to the grass pressing roller through the gearbox, universal joint, etc. When the material to be processed enters between the upper and lower grass pressing rollers, it is clamped by the grass pressing roller. It is held and sent to the guillotine cutting mechanism at a certain speed. Finally chopped corn stalk is thrown out of chaff cutters.

fc 4c 6a structure



CHAFF CUTTER TECHNICAL DATA

Model        FC-2.5A FC-4C FC-6A FC-9A
Capacity (t/h) 1-2.5 2-4 4-6 6-9
Applied Motor (kW) 4 5.5 7.5 15
Applied Diesel Engines (hp) ≥8 ≥12 ≥15 ≥28
Size (mm) 1150×1230

×1695

1020×1520

×2756

1968×2147

×2756

2620×2140

×3390

Weight (kg) 165 310 450 910
Chain Conveyer
Feed Rollers
Tractor Linkage Device × × ×
Diesel Engine Mounting
Pneumatic Tire × ×
√: standard device       ∞: optional device      ×:unavailable device

optional engine chaff cutter 01



CHOOSING A PROPER CHAFF CUTTER MACHINE

There are many fodder chopper machine brands on the market. You need to compare the following aspects when choosing a silage chaff chopper:

High-quality Blades

Fan shape knife blade is composed of #65 Steel by heat treatment processing, and has the advantages of power saving and wear resistance.

chaff cutter blades 5



Unique double gearbox device

Operator users FC-4C Motor-Driven Chaff Cutter Agriculture Machine more simply and more conveniently, a gearbox adjusts straw length, and another can be adjusted the feed raw materials when machine fault, so that users convenience to facilitate the use of straw kneading machine.

chaff cutter gear box2



Gear lever

The advanced feeding and conveying mechanism is controlled by a switch, easy to switch.

chaff cutter gear lever2



Feed Roller

Advanced feeding structure with hay-conveying rollers (for whose patent we have been awarded), the cutter conveys hay automatically and smoothly at a high speed. Feeding Rollers in our FC-4C Motor-Driven Chaff Cutter Agriculture Machines are made by Casting Iron with longer service life.

chaff cutter feeding roller01



CHAFF CUTTER MACHINE FC-4 TEST RUNNING



DELIVERY CHAFF CUTTER MACHINE

Before sending the machine, we will test and adjust chaff cutter machines, so you can use them directly when you get them. Choose the cheapest and safest shipping company to save the cost and track the order until you get the goods.

1. Our company usually packs in standard export wooden case.
2. Transportation means by Air, by Sea or by Express and etc.
3. Shipment cost will depend on the destination, shipment way, and the weight of the goods.
4. You will get full feedback when our agriculture fodder machines are on the way.

chaff cutter shipment



AGRICULTURAL FEED MACHINE WE HAVE

Our agriculture animal feed machines adopt world-famous brand for the key electronic elements, pneumatic and hydraulic system to ensure high quality and reliability of the Agriculture machinery and feed machinery After the unremitting efforts of all staffs, we won the approval and trust of the customers with the excellent performance, advanced technology, and good reputation.

Our Main Products: Chaff Cutter Machine, Grass Chopper Machine for Animals Feed, Fodder Kneading Chopper, Animals Feed Mixer Machine, Pellet Machine, Animals Feed Puffing Extruder, Wood Branch Crusher, Paddy/Wheat Harvester, etc.

chaff cutter machine manufacturer golden machinery



WHAT SERVICES YOU WILL HAVE

Pre-sale Service

1. Offering overall technology and business consultation services;

2. Proposing the most suitable scheme and equipment for our customer;

3. Designing and producing machines according to the special demands of clients;

After-sales Service

1. Carefully checking the machine in every working procedure, quality comes first;

2. Assisting our clients with foundation construction of equipment;

3. Dispatching engineers to install and debug the equipment, training the first-line operators on-site;

4. Regularly visit clients to solve production problems and provide our technical support.

We have more than 15 years of experience, and support your best before and after-sales service. Quality is the first and top Pursuit of our company.

Product list

Forage Cutter +
 – FC-2.5E Mini Type Chaff Cutter
 – FC-2.5D Mini Type Chaff Cutter
 – FC-2.5TC Mini Type Chaff Cutter
 – FC-4C Animal Feed Chopper
 – FC-4D Animal Feed Chopper
 – FC-4TC Animal Feed Chopper
 – FC-6A Multifunction Fodder Chopper
 – FC-6D Multifunction Fodder Chopper
 – FC-6TA Multifunction Fodder Chopper
 – FC-9A Livestock Silage Chopper
 – FC-9TC Livestock Silage Chopper

Feed Chopping Machine +
 – Grain Crop Cereal Grinder
 – Corn Maize Mill Machine
 – Cutting/Kneading/Grinding 3in1 Machine

Feed Mixing Machine +
 – Horizontal Powder Mixer
 – Vertical Poultry Feed Mixer
 – TMR Dairy Feed Crush Mixer

Feed Processing Machine +
 – Flat Die Feed Pellet Mill
 – Floating Sinking Pellet Extruder
 – Ring Die Granulator

More Agriculture Machine +
 – Wood Branch Chipper Machine
 – Compact Wheel Loader
 – Corn Straw Silage Harvester

FAQ & Our service

Are you a manufacturer?
We are a professional OEM manufacturer, have 3000 square meters factory.

MOQ?
1 set, or based on your order, wholesale discount.

Voltage?
220V /380V /415V, 50/60 HZ, 1 or 3 phases, customize the voltage according to your local voltage.

Delivery?
Delivery Time, 7-15 days after getting payment. (Specific time according to order quantity)

Packaging?
When packaged, the main body and parts will be packaged individually depending on the structure of the machine, but it is easy to install.

Guarantee?
The quality guarantee term is for one year, with free technical support and spare parts supply.

Payment term?
T/T, Credit card, Western Union, RMB, Alipay, WeChat, Cash, E-checking, MoneyGram, L/C, etc.

How To Order?
S.1: Inquiry the machine model and quantity you need;
S.2: A quotation for you to confirm the order details;
S.3: You payment after receiving our PI file;
S.4: We deliver goods within stipulated time.
