Horizontal Powder Mixer

This machine is especially suitable for wet and dry feed materials. It needs to be filled with water or oil, mixing powder, granular, flake, block, irregular and sticky materials in feed, cereal, food, chemicals, medicines, pesticide, etc.

Email: info@foragecutter.com

Online(Whatsapp): 008618272564146

hea742453e92d4fecbaa357db9b518336s

WHAT CAN OUR HORIZONTAL FEED MIXER MACHINE DO?

Horizontal Feed Mixer covers a small area, has wide applicability, and is mechanical equipment that uses mechanical force and gravity to evenly mix two or more kinds of materials.

The U-type horizontal feed mixer and grinder machine put in a horizontal position, mixed with high efficiency, good quality, unloading quickly, less remain, adapt to the wide range. So far it is the most commonly used mixer.

The materials put into the machine are Powder material, which also can add a variety of liquids(such as water, molasses, oil, etc.), mixing time (3-5minutes/batch), and mixing uniformity is high (CV<5%).Low residue at one end. It is also suitable for mixing powder materials such as premix poultry, aquatic feed, and ruminant feed. Widely used in compound feed mills, premix plants, and chemical, food, flour, and other industries.

feed mixer application

OUR HORIZONTAL FEED MIXER FEATURES

  • This feed mixer machine is set crushing and mixing equipment, After crushing feed automatically into the mixing step.
  • The raw material can be grain, corn, soybean, wheat, etc., and the special feed can be added to the machine to mix.
  • The feed mixer machine is suitable for family use and small factories.
  • This feed mixer machine possesses lower conception, less area of occupancy, easily to loading and discharge, but long mixing time.
  • The feed mixer machine is generally used for small feed factories and complete feeding lines.
  • High performance-cost ratio.



WORKING PRINCIPLE OF HORIZONTAL FEED MIXER

All kinds of materials according to specified proportion go into the mixer after measurement, materials mixed by the push of ribbon spiral blade. The out screw belt will push the materials from one end to the other end, the inner screw makes the materials move in the opposite direction, the layer material is pushed to one side, then turning from outer to inside.The material in the process of convection mutual infiltration, displacements, and blending on both sides in the process of rolling again, repeated mix many times, finally through the material control structure will discharging the mixing materials from the discharged door.

1. It is composed of the u-shaped container, screw belt stirring blade, and transmission parts;
2. The u-shaped long cylinder structure ensures the small resistance movement of mixed materials (powder and semi-fluid) in the cylinder.
3. Positive and negative rotating screw bars are installed on the same horizontal axis to form a mixed environment with low power and high efficiency. Spiral belt blades are generally made into two or three layers. Speed up the mixing speed, and improve the mixing uniformity;

feed mixer working principle

horizontal feed mixer structure1

HORIZONTAL FEED MIXER TECHNICAL DATA

Capacity 200-250kg/hr
Power 3kw(3 -phase)  /4kw(2-phase)optional
Thickness of machine 3mm
Size 1.75*0.75*2.4m
Packing plywood case for sea
Weight 342kg





CHOOSING A CORRECT HORIZONTAL FEED MIXER?



Choose a reliable Horizontal feed mixer machine looks all same outside. So the quality will be more or less similar. Please change your views right now. Ribbon Blender Powder Mixer from a small workshop must be much more cheap compared with these mixers from larger factories, however, the texture of metal will be a tremendous difference. In general, stainless steel 4Cr13 means the carbon content is 0.4% and chrome content is 13%. The higher the carbon content and lower the chrome content, the easier the metal to be oxidized.

The two ends of the body are double deck design to eliminate the phenomenon of two shaft ends; the outlet door adopts pneumatic (also electric or manual), the action is more accurate and reliable, the sealing performance is good, the oil adding pipe is installed in the machine, the overall structure is reasonable, the appearance is beautiful, and the operation maintenance is convenient.

horizontal feed mixer details0102
horizontal feed mixer details030405



HORIZONTAL POWDER MIXER TEST RUNNING





DELIVERY FEED CUTTING GRINDER MACHINE

Before sending the Horizontal powder mixer machine, we will test and adjust, it so you can use it directly when you get it. Choose the cheapest and safest shipping company to save the cost and track the order until you get the goods.

Package:

1. Feed mixer machines will be packed in standard quantities boxes, the production will have a safe and complete journey from our factory to your place.
2. Packaging details standard export wooden case or in the container.
Strong plywood case as exported standard, if your order is big we suggest shipping by container, we will calculate the total volume of your order and saving shipping cost for you.

Shipping:
By sea, By air; Express (DHL/FedEx; Railway; Highway)
1, we will serve your shipping method for ocean transport, airlift, freight, and so on.
2, The delivery time is usually 7-15 working days upon receipt of your payment.

feed mixer delivery shipment





AGRICULTURAL FEED MACHINE WE HAVE

Our agriculture farm feed machines adopt a world-famous brand for the key electronic elements, pneumatic and hydraulic system to ensure high quality and reliable of the Agriculture machinery and feed machinery After the unremitting efforts of all staff, we won the approval and trust of the customers with the excellent performance, advanced technology, and good reputation.

Our Main Products: Chaff Cutter Machine, Grass Chopper Machine for Animals Feed, Fodder Kneading Chopper, Animals Feed Mixer Machine, Pellet Machine, Animals Feed Puffing Extruder, Wood Branch Crusher, Paddy/Wheat Harvester, etc.

chaff cutter machine manufacturer golden machinery



WHAT SERVICES YOU WILL HAVE

Pre-sale Service

1. Offering overall technology and business consultation services;

2. Proposing the most suitable scheme and equipment for our customer;

3. Designing and producing machines according to the special demands of clients;

After-sales Service

1. Carefully checking the machine in every working procedure, quality comes first;

2. Assisting our clients with foundation construction of equipment;

3. Dispatching engineers to install and debug the equipment, training the first-line operators on-site;

4. Regularly visit clients to solve production problems and provide our technical support.

We have more than 15 years of experience, and support your best before and after-sales service. Quality is the first and top Pursuit of our company.
